240
Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
Setting the timing of transition completion
When the execution mode for a DME wipe crop transition is set to [Last 5%],
you can select the timing of transition completion from 70% ([Last 30%]), 95%
([Last 5%]), and 100% ([Off]).
1 In the M/E 1 >DME Wipe menu, select HF5 ‘Modify’.
The Modify menu appears.
2 In the <Crop Mode> group select [Remove From Begin].
The Remove From Begin menu appears.
3 In the <Release Transition> group, select the timing of transition
completion.
Last 30%: The transition completes at the end of 70% of the transition
execution time. The transition has a dead zone from 70% to 95% of the
transition time.
Last 5%: The transition completes at the end of 95% of the transition
execution time. When the transition completes, the cropping is
removed during the last 5%.
Off: The transition completes at the end of the transition execution time.
During the last 5% of the transition, the transition and cropping
removal proceed together.
0
100 (%)
y
t
(%)
100
0
100 (%)95
y
t
(%)
100
95
0
100 (%)
[Cut] [Last 5%] [Linear]
y
t
(%)
100
Transition
Cropping
Transition
Cropping
Transition
Cropping
t: transition execution time
y: change in transition and cropping amount
