314
Copy and Swap
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
DME wipe copy and DME wipe swap in the independent key
transition control block
You can copy and swap the DME wipe settings among the keyers listed in the
following table.
Matte data copy and swap
You can copy or swap the matte data among the color generators listed in the
following table.
Color data copy and swap
You can copy or swap the color data among the color generators listed in the
following table.
DME channel copy and swap
You can copy and swap the channel data among DME channels 1 to 2.
Target bank Target keyer Target data
M/E-1 Keys 1 to 4 DME wipe settings in the independent
key transition control block.
PGM/PST Downstream keys 1 to 4
Target bank Target keyer and data
M/E-1
PGM/PST
• Keys 1 to 4
• Downstream keys 1 to 4
• Matte data for key fill
• Matte data for key edge fill
Matte data for wipe border edge
Color background • Matte data for color background 1
Target bank Target keyer and data
M/E-1
PGM/PST
• Keys 1 to 4
• Downstream keys 1 to 4
• Colors 1 and 2 for key fill
• Colors 1 and 2 for key edge fill
• “Zabton” color data
Matte data for wipe border
Color background • Colors 1 and 2 for color background 1
Frame memory • FM1 color
• FM2 color
DME ch1, ch2
DME ch4 to ch8
• Background
•Border
• Sepia
• Light
• Shade
• Drop shadow
•Trail
