Chapter 9 Color Corrector
338
Color Corrector Functions
4
Depending on the selection in step 3, adjust the following parameters.
• When Black or Gamma is selected
• When White is selected
• When Knee is selected
To return the parameters to their default settings
In the
<Primary CCR>
group, press
[Unity].
Masking a part of the primary color correction
Here the procedure for mask 1 operation is described by way of example. You
can carry out mask 2 operation in a similar way.
1
In the <Primary Mask> group of the Primary CCR menu, press [Mask1],
turning it on.
2
Press [Mask1 Adjust].
The Mask1 Adjust menu appears.
3
In the <Mask Source> group, select the mask source.
Box: signal from dedicated box generator
Pattern: signal from dedicated pattern generator
Knob Parameter Adjustment Setting values
1 Red Red signal adjustment –100.00 to +100.00
2 Green Green signal adjustment –100.00 to +100.00
3 Blue Blue signal adjustment –100.00 to +100.00
4 All Simultaneous RGB adjustment Red value is shown
Knob Parameter Adjustment Setting values
1 Red Red signal adjustment 0.00 to 200.00
2 Green Green signal adjustment 0.00 to 200.00
3 Blue Blue signal adjustment 0.00 to 200.00
4 All Simultaneous RGB adjustment Red value is shown
Knob Parameter Adjustment Setting values
1 Red Red signal adjustment 20.00 to 75.00
2 Green Green signal gain 20.00 to 75.00
3 Blue Blue signal gain 20.00 to 75.00
4 All Simultaneous RGB adjustment Red value is shown
