AM tuner section
Tuning range
With IO-kHz. tuning scale
530-1,710kHz
3
)
With 9-kHz tuning scale
531-1,710kHz
3
)
Freljuency response
PHONO
MULTI CHANNEL
INPUT, SA-CD/CD.
MDIDAT. DVD/BD,
TV. SAT/CATV.
VIDEO 1/2/3
RIAA equalization curve
± 0.5 dB
10Hz-100kHz
±3 dB
Antenna (aerial)
Loop antenna (aerial)
Inputs (Analog)
PHONO
MULTI CHANNEL
INPUT. SA-CD/CD.
MD/DAT. DVD/BD, TV,
SAT/CATV,
VIDEO 1/2/3
Inputs (Digital)
DVD/BD. VIDEO 2.
SA-CD/CD (Coaxial)
VIDEO I. TV.
SAT/CATV.
TAPE/CDR.
MDIDAT (Optical)
Outputs
MD/DAT (REC OUT).
VIDEO I. ZONE 2,
ZONE 3 (AUDIO OUT)
FRONT LlR. CENTER.
SURROUND LlR.
SURROUND BACK UR.
SUB WOOFER
EQUALIZER
Sensitivity: 2.5mV
Impedance: 50kohms
SIN: 90dB
(A. 20 kHz
LPF)
Sensitivity: 150mV
Impedance: 50kohms
SIN: 100dB (A. 20 kHz
LPF)
Impedance: 750hms
SIN: 9MB (A. 20 kHz
LPF)
SIN: 96 dB
(A. 20 kHz LPF)
Voltage: 150mV
Impedance: Ikohm
Voltage: 2V
Impedance: 1kohm
.')You
can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE. press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10kHz, (or 9
kHz).
repeat the procedure.
Video section
Inputs/Outputs
Video: I Vp-p, 75 ohms
COMPONENT VIDEO:
V: I Vp-p, 75 ohms
PB/e
B
: 0.7
Vp-p, 75 ohms
PR/C
R
: 0.7
Vp-p, 75 ohms
80
MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 x 480p@60 Hz.
no x 480p@59,94/60 Hz
1440 x 480p@59.94/60 Hz (pixel sent 2times)
1280 x
nOp@59.94/60 Hz
1920 x 1080i@S9,94/60 Hz
1920 x 1080p@59.94/60 Hz
no x 576p@50 Hz.
1440 x 576p@50 Hz (pixel scnt 2times)
1280 x nOp@50 Hz
1920 x 1080i@50 Hz
1920 x 1080p@SO Hz
1920 x I 080p@24 Hz
Gain levels ±IO dB, I dB step
FM tuner section
Tuning range 87.5 - 108.0 MHz.
Antenna (aerial)
FM wire antcnna (acrial)
Antenna (aerial) terminals
75 ohms, unbalanced
