3.4 Elements of delivery
3.4.1 Basic equipment
Table machine with base plate (basic machine SM100)
1 Technical manual
1 Socket screw wrench, 5mm, 6edges
1 Grease gun, 1 cable
1 socket wrench/box spanner for grinding wheel flange
Basic body with motor and complete electrical equipment 230V, 50/60 Hz
Quick change device for grinding wheel
Grinding wheel cover with wheel dresser without diamond
T-groove ledge to fix accessories
3.4.2 Special equipment
1) Grinding wheel flange
2) Grinding wheels in form T/I/II/III
3) Dressing diamond
4) Support for the hands (all-round adjustable)
5) Swivel holder with cross slide
6) Support for square tools with clamp
7) Dividing apparatus for collets 355E up to 17,5mm
8) Dividing apparatus for collets W25 up to 25mm or with reducing for collets
W20 up to 20mm
9) Single collets or sets
10) Collets with special design
11) Inserts W25 with MK1/2/3
12) Special clamping device
The table machine can be extended with:
1) Base SM100
2) Tank with coolant supply
ONLY USE ORIGINAL REPLACEMENT PARTS AND
ACCESSORIES FROM SPINNER!
