Spinner SM100 - Figure 5-3: Coolant Pump

5-3
 SPINNER Werkzeugmaschinenfabrik GmbH
SM-1-03/02
Electrical connection
Coolant pump:
The plug of the coolant pump has an integrated switch. When the coolant pomp is
switched on it will only start when the grinding wheel starts. If the grinding wheel is
switched off, the coolant pomp is also stopped.
Figure 5-3: Coolant pump
