6.1 Maintenance instruction
Grinding spindle:
The cone of the grinding spindle must always be kept clean. Cleaning should be carried
out with each grinding wheel change.
Grinding wheel flange:
The inner cone of the flange must always be kept clean. Cleaning should be carried out
with each grinding wheel change.
Figure 6-1: Maintenance instructions for the grinding spindle
Greasing the swivel holder:
A central lubrication nipple is located on the swivel holder. With the use of a suitable
grease press lubrication should be carried out approx. Every week depending on demand.
For this, use a customary multi-purpose grease.
Figure 6-2: Lubricating the swivel holder
Lubricating the dividing apparatus
A central lubrication nipple is located on the dividing apparatus. With the use of a suitable
grease press, lubrication should be carried out approx. Every week depending on
demand. For this, use a customary multi-purpose grease.
