0458-185-9821-A
53
English
17 Repairing
Use a STIHL flat file to sharpen each cutting edge on the
upper blade. The file only sharpens on the forward stroke.
Maintain the prescribed sharpening angle, @ 19.2.
Turn the long-reach hedge trimmer over.
Sharpen the remaining cutting edges.
Deburr each cutting edge from below.
Turn the long-reach hedge trimmer over.
Deburr the remaining cutting edges.
Use a damp cloth to remove the filing dust.
Spray both sides of cutting blades with STIHL resin
solvent.
Switch on the long-reach hedge trimmer for 5 seconds.
The cutting blades run. STIHL resin solvent is distributed
evenly.
If you have any doubts, be sure to consult a STIHL dealer.
17.1 Repairing the Hedge Trimmer and Battery
The hedge trimmer, cutting blades and battery cannot be
repaired by the user.
If the hedge trimmer or cutting blades are damaged: Do
not use your hedge trimmer and contact your STIHL
servicing dealer.
If the battery has a malfunction or is damaged: Replace
the battery.
17 Repairing
0000-GXX-1426-A0

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl HLA 86 and is the answer not in the manual?

Stihl HLA 86 Specifications

General IconGeneral
Power SourceBattery
Rated Voltage36 V
Blade Length60 cm
Weight4.5 kg
Stroke Rate3, 000 spm
Cutting Length60 cm
