Stihl HLA 86 User Manual

0458-185-9821-A
56
English 19 Specifications
19.1 STIHL HLA 66, HLA 86 Long-Reach Hedge
Trimmers
HLA 66
– Permitted batteries:
–STIHL AP
–STIHL AR
– Weight without battery: 3.8 kg
– Degree of electrical protection: IPX4 (protection against
splash water from any direction)
HLA 86
– Permitted batteries:
–STIHL AP
–STIHL AR
– Weight without battery: 4.8 kg
– Degree of electrical protection: IPX4 (protection against
splash water from any direction)
The running time is shown at www.stihl.com/battery-life.
19.2 Cutting blades
HLA 66
– Tooth spacing: 33 mm
– Cutting length: 500 mm
– Sharpening angle: 45°
HLA 86
– Tooth spacing: 33 mm
– Cutting length: 500 mm
– Sharpening angle: 45°
19.3 STIHL AP battery
– Battery Technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation and storage:
-10°C to +50°C
19.4 Sound Values and Vibration Values
K-value (uncertainty) for sound pressure levels is 2 dB(A).
K-value (uncertainty) for sound power levels is 2 dB(A). The
K-value for vibration levels is 2 m/s².
HLA 66
STIHL recommends wearing ear defenders.
– Sound pressure level L
pA
measured according to
ISO 22868: 85 dB(A)
– Sound power level L
wA
measured according to
ISO 22868: 94 dB(A)
– Vibration level a
hv
measured according to ISO 22867
– Control handle: 3.5 m/s²
– Loop handle: 3.5 m/s²
HLA 86
STIHL recommends wearing ear defenders.
– Sound pressure level L
pA
measured according to
ISO 22868: 85 dB(A)
– Sound power level L
wA
measured according to
ISO 22868: 94 dB(A)
– Vibration level a
hv
measured according to ISO 22867
– Control handle: 2.0 m/s²
– Handle hose: 2.0 m/s²
19 Specifications

Stihl HLA 86 Specifications

General

Power Source	Battery
Rated Voltage	36 V
Blade Length	60 cm
Weight	4.5 kg
Stroke Rate	3, 000 spm
Cutting Length	60 cm
