If the carburetor has been set correctly,
the abrasive wheel should not rotate
when the engine is idling.
The cut-off machine is now ready for
use.
Switching off the engine
N Slide control(3) toSTOPor0
Additional hints on starting
If the engine does not start
The choke lever was not returned to f
in time after the engine turned over for
the first time.
N Slide control to START = starting
throttle position
N Set the choke lever to e = warm
start, even if the engine is cold
N Pull the starter rope through 10
-
20
times to ventilate the combustion
chamber
N Restart the engine
If the tank has been drained completely
N Refuel
N Press the manual fuel pump bulb
7
-
10times – even if it is full of fuel
N Set the choke lever in accordance
with the engine temperature
N Restart the engine
Basic information
The average filter life is more than
1year. Do not dismantle the filter cover
or fit a new air filter unless there is a
noticeable loss of engine power.
In the long-life air filter system with the
cyclone pre-separation system, dirty air
is drawn in and deliberately rotated. The
larger and heavier particles carried in
the air are thus expelled and extracted.
Only pre-cleaned air enters the air filter
system and the result is extremely long
filter life.
370BA059 KN
START
3
Air Filter System
