Stihl TS 420 Instruction Manual

TS 410, TS 420
English
38
1 Rear Handle
2 Throttle Trigger Lockout
3 Throttle Trigger
4 Slide Control
5 Starter Grip
6 Carburetor Adjusting Screws
7 Fuel Filler Cap
8 Water Attachment
9 Tensioning Nut
10 Adjusting Lever
11 Abrasive Wheel
12 Front Thrust Washer
13 Guard
14 Muffler
15 Spark Arresting Screen
16 Front Handle
17 Decompression Valve
1)
18 Cap for Spark Plug Boot
19 Choke Lever
20 Manual Fuel Pump
21 Filter Cover
# Serial Number
A Warning Label
B Warning Label
C Warning Label
D Warning Label
E Warning Label
Main Parts
18
17
D
E
C
5
10
#
21
20
19
13
16
11
9
8
7
4
A
14
15
B
3
370BA103 KN
1
2
6
1)
Depending on Model

Stihl TS 420 Specifications

General

Engine Power	4.4 bhp
Weight	21.2 lbs
Arbor Size	20 mm
Maximum Wheel Size	350 mm
Maximum Cutting Depth	125 mm
Displacement	66.7 cc (4.1 cu. in.)
Fuel Capacity	710 cc
