102 TS 410, TS 420
No. Part name Part No. Use Re-
marks
20 Wooden assembly block 1108 893 4800 Locate piston
21 Service tool ZS 5910 007 2200 Remove crankshaft
22 Press arbor 4119 893 7200 Drive grooved ball bearings out of
spindle bearing
23 Press arbor 4224 893 7200 Drive grooved ball bearing out of poly
V-belt pulley
24 Stud puller, M8 5910 893 0501 Unscrew studs for attaching the cast
arm with guard
25 Assembly hook 5910 893 8800 Remove pickup body
26 Test disk 5910 851 6100 Test axial truth of running of the cutting
wheel mount
27 Dial gauge holder 5910 850 6000 Test axial truth of running
28 Dial gauge 0000 890 9100 Test axial truth of running
29 Torque wrench with optical/
acoustic signal
5910 890 0302 Screw connections (0.5 to 18 Nm)
(with visual and acoustic signaling)
30 Torque wrench with optical/
acoustic signal
5910 890 0312 Screw connections (6 to 80 Nm)
(with visual and acoustic signaling)
31 Socket, T27x125 0812 542 2104 Remove and install spline socket head
screws with electric or pneumatic
screwdrivers; tighten down screws with
torque wrench
1)
32 Screwdriver T27x150 5910 890 2400 IS-P screws (4 mm) 1)
33 Pliers A10 0811 611 8200 Remove and install external retaining
rings
34 Pliers C19 0811 641 8380 Remove and install internal retaining
rings
Remarks:
1) Use only for releasing.
