7TS 410, TS 420
3.5 Tightening torques
DG and P screws are fitted in plastic and light alloy metal parts. These screws form a permanent thread when
they are installed for the first time. The material is permanently deformed. Screws can be removed and installed
as often as necessary without impairing the strength of the screwed assembly, provided that the specified
tightening torque is observed.
For this reason, it is essential to use a torque wrench.
Fastener Thread size For component Tightening
torque
Remarks
Nm
Bolt M 6x28 Cast arm / flange 8.0
Nut M 8 Cast arm/ starter cover/stud 20.0
M 10x1 Decompression valve 14.0
Bolt M 5x20 Filter cover / tank housing 6.0
Bolt P 5x16 Handle molding / shroud 4.0
Bolt D 5x20 Rubber buffer /support 6.0
Bolt P 5x16 Holder / switch /shroud 3.0
Bolt P 6x19 Holder /water attachment / tank housing 6.0
Bolt P 6x19 Shroud / tank housing 6.0
Bolt M 5x17 Cap, spark plug cover / shroud 3.5
Nut M 10x1 L Poly V-belt pulley, front 38.0
Bolt P 6x40 Clamp /handlebar/ tank housing 6.0
Bolt P 6x26 Clamp / tank housing 6.0
Bolt D 5x45 Clamp (AV system) / handlebar support 4.0
Bolt P 6x19 Crankcase/ bearing plug (AV system) 6.0
Bolt M 5x32 Crankcase/ cylinder 9.0
Bolt M 5x25 Crankcase fan side/drive side 10.0
M 12x1 L Driver 40.0
Bolt M 5x6 Bearing / rubber buffer 4.0 1)
Bolt P 5x16 Bearing plug AV system / tank housing 4.0
Bolt M 5x20 Fan cover / crankcase 6.0
Bolt P 6x19 Air baffle /tank housing 6.0
Bolt M 5x20 Air guide shroud / crankcase 3.0
Bolt M 5x20 Muffler /crankcase 10.0
Bolt M 5x20 Muffler/ cylinder 10.0
Bolt M 5x30 Belt guard / cast arm 6.0
Nut M 8x1 Flywheel/crankshaft 33.0 2)
Bolt D 5x24 Clamping lever/cast arm 4.0
Bolt M 3x20 Hose clamp, manifold / cylinder 0.5
Nut M 8x1 Starter cup /crankshaft 33.0
Bolt M 8x53 Stud / crankcase 21.0
Bolt P 6x50 Support/ clamp / handlebar /tank
housing
6.0
