Pinouts and pin description STM32F038x6

32/102 DocID026079 Rev 3

Table 13. Alternate functions selected through GPIOB_AFR registers for port B

Pin name AF0 AF1 AF2 AF3

PB0 EVENTOUT TIM3_CH3 TIM1_CH2N -

PB1 TIM14_CH1 TIM3_CH4 TIM1_CH3N -

PB2----

PB3 SPI1_SCK, I2S1_CK EVENTOUT TIM2_CH2 -

PB4 SPI1_MISO, I2S1_MCK TIM3_CH1 EVENTOUT -

PB5 SPI1_MOSI, I2S1_SD TIM3_CH2 TIM16_BKIN I2C1_SMBA

PB6 USART1_TX I2C1_SCL TIM16_CH1N -

PB7 USART1_RX I2C1_SDA TIM17_CH1N -

PB8 - I2C1_SCL TIM16_CH1 -

PB9 IR_OUT I2C1_SDA TIM17_CH1 EVENTOUT

PB10 - I2C1_SCL TIM2_CH3 -

PB11 EVENTOUT I2C1_SDA TIM2_CH4 -

PB12 SPI1_NSS EVENTOUT TIM1_BKIN -

PB13 SPI1_SCK - TIM1_CH1N -

PB14 SPI1_MISO - TIM1_CH2N -

PB15 SPI1_MOSI - TIM1_CH3N -
