Page #9 background image
DocID026079 Rev 3 9/102
STM32F038x6 Description
22
2 Description
The STM32F038x6 microcontrollers incorporate the high-performance ARM
®
Cortex
®
-M0
32-bit RISC core operating at up to 48 MHz frequency, high-speed embedded memories
(32 Kbytes of Flash memory and 4 Kbytes of SRAM), and an extensive range of enhanced
peripherals and I/Os. All devices offer standard communication interfaces (one I
2
C, one
SPI/ I
2
S and one USART), one 12-bit ADC, five 16-bit timers, one 32-bit timer and an
advanced-control PWM timer.
The STM32F038x6 microcontrollers operate in the -40 to +85 °C and -40 to +105 °C
temperature ranges at a 1.8
V ± 8% power supply. A comprehensive set of power-saving
modes allows the design of low-power applications.
The STM32F038x6 microcontrollers include devices in five different packages ranging from
20 pins to 48 pins with a die form also available upon request. Depending on the device
chosen, different sets of peripherals are included.
These features make the STM32F038x6 microcontrollers suitable for a wide range of
applications such as application control and user interfaces, hand-held equipment, A/V
receivers and digital TV, PC peripherals, gaming and GPS platforms, industrial applications,
PLCs, inverters, printers, scanners, alarm systems, video intercoms and HVACs.
Table 2. STM32F038x6 family device features and peripheral counts
Peripheral STM32F038Fx STM32F038Ex STM32F038Gx STM32F038Kx STM32F038Cx
Flash memory (Kbyte) 32
SRAM (Kbyte) 4
Timers
Advanced
control
1 (16-bit)
General
purpose
4 (16-bit)
1 (32-bit)
Comm.
interfaces
SPI [I
2
S]
(1)
1 [1]
I
2
C1
USART 1
12-bit ADC
(number of channels)
1
(8 ext. + 3 int.)
1
(9 ext. + 3 int.)
1
(10 ext. + 3 int.)
GPIOs 14 19 22 26 38
Max. CPU frequency 48 MHz
Operating voltage V
DD
= 1.8 V ± 8%, V
DDA
= from V
DD
to 3.6 V
Operating temperature
Ambient operating temperature: -40°C to 85°C / -40°C to 105°C
Junction temperature: -40°C to 105°C / -40°C to 125°C
Packages TSSOP20 WLCSP25 UFQFPN28 UFQFPN32 LQFP48
1. The SPI interface can be used either in SPI mode or in I
2
S audio mode.
