STMicroelectronics STM32F038C6 - Table 23. Typical and Maximum Consumption in Stop Mode

DocID026079 Rev 3 45/102
STM32F038x6 Electrical characteristics
79
Table 22. Typical and maximum current consumption from the V
DDA
supply
Symbol Parameter
Conditions
(1)
f
HCLK
V
DDA
= 2.4 V V
DDA
= 3.6 V
Unit
Typ
Max @ T
A
(2)
Typ
Max @ T
A
(2)
25 °C 85 °C 105 °C 25 °C 85 °C 105 °C
I
DDA
Supply
current in
Run or
Sleep
mode,
code
executing
from Flash
memory or
RAM
HSE
bypass,
PLL on
48 MHz 147 170 180 184 160 183 195 199
µA
32 MHz 101 121 127 129 109 129 137 140
24 MHz 79 97 101 103 86 104 110 112
HSE
bypass,
PLL off
8 MHz13332334
1 MHz12222233
HSI clock,
PLL on
48 MHz 219 243 256 260 240 267 279 284
32 MHz 172 195 203 206 190 210 222 226
24 MHz 150 170 177 180 165 186 193 196
HSI clock,
PLL off
8 MHz7183878881959798
1. Current consumption from the V
DDA
supply is independent of whether the digital peripherals are enabled or disabled, being
in Run or Sleep mode or executing from Flash memory or RAM. Furthermore, when the PLL is off, I
DDA
is independent from
the frequency.
2. Data based on characterization results, not tested in production unless otherwise specified.
Table 23. Typical and maximum consumption in Stop mode
Symbol Parameter Conditions
Typ. @ V
DD
= 1.8 V Max
Unit
V
DDA
= 1.8 V
V
DDA
= 2.0 V
V
DDA
= 2.4 V
V
DDA
= 2.7 V
V
DDA
= 3.0 V
V
DDA
= 3.3 V
V
DDA
= 3.6 V
T
A
= 25 °C
T
A
= 85 °C
T
A
= 105 °C
I
DD
Supply
current in
Stop mode
All oscillators OFF
0.4 2.3 14.9 35.6
µA
I
DDA
0.8 0.8 0.8 0.9 0.9 1.0 1.1 1.5 2.6 3.4
