STMicroelectronics STM32F038C6 User Manual

DocID026079 Rev 3 51/102
STM32F038x6 Electrical characteristics
79
APB
APB-Bridge
(2)
2.6
µA/MHz
SYSCFG 1.7
ADC
(3)
4.2
TIM1 17.1
SPI1 9.6
USART1 17.4
TIM16 8.2
TIM17 8.0
DBG (MCU Debug Support) 0.5
TIM2 17.4
TIM3 12.8
TIM14 6.0
WWDG 1.5
I2C1 5.1
PWR 1.2
All APB peripherals 110.9
1. The BusMatrix automatically is active when at least one master is ON (CPU or DMA1).
2. The APBx Bridge is automatically active when at least one peripheral is ON on the same Bus.
3. The power consumption of the analog part (I
DDA
) of peripherals such as ADC is not included. Refer to the
tables of characteristics in the subsequent sections.
Table 27. Peripheral current consumption (continued)
Peripheral Typical consumption at 25 °C Unit

STMicroelectronics STM32F038C6 Specifications

General

Series	STM32F0
Core	ARM Cortex-M0
Operating Frequency	48 MHz
Flash Memory Size	32 KB
RAM Size	4 KB
Number of I/Os	39
ADC Resolution	12-bit
ADC Channels	10
Operating Temperature	-40°C to 85°C
Operating Voltage	2.0 V to 3.6 V
Communication Interfaces	I2C, SPI, USART
Package	LQFP48
