www.stryker.com 6390-009-002 REV D 9
Introduction
Specifications
Safe working load
Note: Safe working load represents the sum of the
cot total weight and patient
870 lb
395 kg
Maximum lift capacity (patient and accessories)
700 lb 318 kg
Overall length
95 in. 241 cm
Minimum length 89.5 in. 228 cm
Width 24.5 in. 62 cm
Weight
Floor plate assembly 16.5 lb 7.5 kg
Anchor assembly 23 lb 10.5 kg
Transfer assembly
67 lb 30.5 kg
Trolley assembly 105 lb 48 kg
Minimum operators required for loading/unloading an
occupied cot
2
Minimum operators required for loading/unloading an
unoccupied cot
1
Recommended loading height 22 in. to 36 in. 56 cm to 91 cm
Hydraulic oil
Mobil Mercon® V Blend ATF Oil (6500-001-293)
See the Mobil Mercon V Blend ATF oil material
safety data sheet (MSDS) for safety information.
Electrical requirements
12.8 VDC-15.6 VDC, 15A fuse/breaker, 2 conductor
10 AWG cable
Battery duty cycle, charging 100%
Battery duty cycle, loading
10% (33 sec on/5 min off)
Battery
12 VDC, 5 Ah lead acid battery (6390-001-468)
Fuse
LITTELFUSE 0496060.ZXD-UL
Standards ANSI/AAMI ES60601-1:2012, CAN/CSA-C22.2 No.
60601-1:14, KKK-A-1822F, IEC 60601-1-12:2014
For standards that require specific options, see
Standards with required options on page 11.
Stryker reserves the right to change specifications without notice.
The yellow and black color scheme is a proprietary trademark of Stryker Corporation.
Hereby, Stryker declares that the radio equipment type short range device is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: http://techweb.med.
strykercorp.com/EMS/EU%20Declaration%20of%20Conformity/index.html.
Labels may be unreadable from a viewing distance greater than 12 inches.
