Stryker Prime Series User Manual

2266 iinn.. wwiiddtthh
PPrriimmee mmaannuuaall oonnllyy
3300 iinn.. wwiiddtthh
3300 iinn.. wwiiddtthh
PPrriimmee XX oonnllyy
Overall length
85 in. (± .5
in.)
215.9 cm
85 in. (± .5
in.)
215.9 cm
85 in. (± .5
in.)
215.9 cm
Overall length (litter extension
option)
89.9 in. (±
.75 in.)
228.3 cm
89.9 in. (±
.75 in.)
228.3 cm NA NA
Overall width (siderails up)
34 in. (± 1
in.)
86.4 cm
38 in. (± 1
in.)
96.5 cm
38 in. (± 1
in.)
96.5 cm
Overall width (siderails down)
26 in. (± .5
in.)
66 cm
30.5 in. (±
.5 in.)
77.5 cm
30.5 in. (±
.5 in.)
77.5 cm
Minimum height
20.75 in. (±
1 in.)
52.7 cm
20.75 in. (±
1 in.)
52.7 cm 23.25 in. 59.1 cm
Maximum height
34 in. (± 1
in.)
86.4 cm
34 in. (± 1
in.)
86.4 cm
36.5 in. (± 1
in.)
92.7 cm
Maximum
cassette
dimension
Side
Not applicable
19.87 in. 50.5 cm
Head end
Not applicable
21 in.
53.3 cm
Fowler backrest angle 0° to 90° (± 5°)
Gatch height 5.5 in. (14 cm) minimum Not applicable
Trendelenburg/reverse
Trendelelburg
± 17° (± 3°)
Minimum clearance
2.5 in.
nominal
6.4 cm
2.5 in.
nominal
6.4 cm
2.5 in.
nominal
6.4 cm
1.75 in.
under the
hydraulic
jacks
4.5 cm
1.75 in.
under the
hydraulic
jacks
4.5 cm
1.75 in.
under the
hydraulic
jacks
4.5 cm
1 in. under
BBiigg WWhheeeell
2.5 cm
1 in. under
BBiigg WWhheeeell
2.5 cm
1 in. under
BBiigg WWhheeeell
2.5 cm
Attenuation equivalent (aluminum
equivalence)
Not applicable
Maximum value allowed
is 1.7 mm Al
Scale system weight operating
range
50 lb (22.7 kg) to 700 lb (318 kg)
Scale system accuracy
± 3 lb (1.3 kg) for weights less than 100 lb (45 kg) and ±3% for weights greater
than or equal to 100 lb (45 kg)*
*To meet the scale system accuracy claim, the patient surface must be in the flat position (Fowler backrest and Gatch
down) and the product cannot exceed 5 degrees of Trendelenburg/reverse Trendelenburg.
EElleeccttrriicc EElleeccttrriicc lliitttteerr EElleeccttrriicc lliifftt
Electrical requirements
120 VAC, 60Hz, 10A
240 VAC, 50/60 Hz, 5A
120 VAC, 60Hz, 10A
240 VAC, 50/60 Hz, 5A
Duty cycle
Continuous operation with intermittent
loading is 1 min. ON/20 min. OFF
Continuous operation with intermittent
loading is 1 min. ON/20 min. OFF
1115-309-001 Rev AD.0 9 EN

Stryker Prime Series Specifications

General

Model	Prime Series
Category	Medical Equipment
Power Requirements	120V AC, 60Hz
Battery Backup	Yes
Type	Medical Bed
Weight Capacity	500 lbs
Features	integrated scale
Compatibility	Compatible with Stryker
