Stryker Prime Series User Manual

To place the product in the recovery chair position (Figure 18):
FFiigguurree 1188 –– RReeccoovveerryy cchhaaiirr ((MMooddeell 11111155 sshhoowwnn))
1. Raise the Fowler backrest to a seated position. See
Raising or lowering the Fowler backrest, non-electric litter (page 28)
or
Raising or lowering the Fowler backrest, electric litter (page 28).
2. Raise the Gatch to the highest height position. See
Raising or lowering the Gatch, non-electric litter (page 29) or Raising
or lowering the Gatch, electric litter
(page 29).
3. Raise the product to the highest height position. See
Raising the product (page 20).
4. Place the product into the reverse Trendelenburg position. See
Positioning the product in reverse Trendelenburg (page
21).
5. Reverse steps to return the product to a horizontal position.
SSttoorriinngg oobbjjeeccttss iinn tthhee bbaassee hhoooodd
CCAAUUTTIIOONN
• Do not place objects that exceed 60 lb (27 kg) in the base hood.
• Do not sit, step, or stand on the base hood.
You can store patient belongings in the base hood. Do not use the oxygen bottle holder cutout to store oxygen bottles or
patient belongings.
HHaannggiinngg ddeevviicceess wwiitthh tthhee ppuummpp rraacckk ooppttiioonn
WWAARRNNIINNGG
• Always keep device lines on the pump rack away from the Gatch handles.
• Always remove any devices that may be in the way before you raise or lower the litter.
• Always make sure that devices on the pump rack can pass through door openings.
• Do not lift the product by the pump rack.
CCAAUUTTIIOONN
• Do not exceed the 40 lb (18 kg) weight capacity of the pump rack.
• Do not use the pump rack as a push/pull device. Product damage may occur.
1115-309-001 Rev AD.0 31 EN

Stryker Prime Series Specifications

General

Model	Prime Series
Category	Medical Equipment
Power Requirements	120V AC, 60Hz
Battery Backup	Yes
Type	Medical Bed
Weight Capacity	500 lbs
Features	integrated scale
Compatibility	Compatible with Stryker
