Stryker Prime Series User Manual

A
B
FFiigguurree 3300 –– RReemmoovvaabbllee IIVV ppoollee
AAttttaacchhiinngg tthhee uupprriigghhtt ooxxyyggeenn bboottttllee hhoollddeerr
WWAARRNNIINNGG
• Do not place objects that exceed 40 lb (18 kg) in the upright oxygen bottle holder.
• Always use caution if the defibrillator tray/foot extender, footboard/chart holder, or upright oxygen bottle holder is
attached to avoid pinching your fingers when you position the foot end push handle option.
The upright oxygen bottle holder supports an oxygen bottle in a vertical position.
To attach the upright oxygen bottle holder:
1. Insert the support bar into any of the IV sockets.
2. Insert the cotter pin through the hole in the support bar to secure the bottle holder to the product.
NNoottee -- Do not use the upright oxygen bottle holder as a push/pull device. Product damage may occur.
EExxtteennddiinngg oorr ssttoowwiinngg tthhee sseerrvviinngg ttrraayy hhoollddeerr//ffoooottbbooaarrdd
WWAARRNNIINNGG -- Do not place objects that exceed 30 lb (14 kg) on the serving tray.
To fit the serving tray on the siderail, pull out on both sides of the serving tray and position the tray over the siderails.
To stow the serving tray:
1. Remove the serving tray from the siderails.
2. Push in the sides of the serving tray.
3. Store the serving tray in the footboard.
NNoottee -- Do not use the serving tray/footboard as a push/pull device. Product damage may occur.
1115-309-001 Rev AD.0 49 EN

Stryker Prime Series Specifications

General

Model	Prime Series
Category	Medical Equipment
Power Requirements	120V AC, 60Hz
Battery Backup	Yes
Type	Medical Bed
Weight Capacity	500 lbs
Features	integrated scale
Compatibility	Compatible with Stryker
