Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Siderail kit, head end
right W/O patient
control pendant, dark
blue, see Siderail
head end assembly
on page 82
YM-KIT-100031-B YM-02-143-MN Right back siderail
assembly
1
HM-22-1780 3M primer 94
handkerchief
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
4
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
4
HM-12-144 12-144 10 x 128 mm
siderail pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-418 Future siderail shock
absorber PLS
2
HM-05-018
M8*90 half thread
steel bolt
1
HM-07-03 M8 iron washer 2
HM-08-06
M8 fibered nut
1
HM-20-852
Dark blue (Stryker)
upper right siderail
color sticker
1
