Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
HM-17-16 BA1812-1300-000
Linak CB6 battery
1
Brake pedal
replacement kit, left
YM-KIT-100082
YM-SV2PDL-001-BY
Pedal sheet weld
assembly
1
YM-HM-02-023 Pedal plastic body
1
HM-20-424
Pedal label-left
1
HM-20-423 Pedal label-right
1
HM-07-22 M6 iron washer
(small)
1
HM-08-05
M6 fibered nut
1
HM-12-905
Transfer laser cut
part bushing (bronz)
1
HM-07-09
Special pedal washer
2
HM-06-86
Ø6 x 16 cross
recessed raised
cheese head screws
2
HM-11-34
Ø13 rue segman
1
HM-06-001 M6 x 25 mushroom
head square neck
bolt
1
Brake pedal
replacement kit, right
YM-KIT-100083
YM-SV2PDL-001-BY
Pedal sheet weld
assembly
1
YM-HM-02-023 Pedal plastic body
1
HM-20-423 Pedal label-right
1
HM-07-22 M6 iron washer
(small)
1
HM-08-05
M6 fibered nut
1
HM-12-905
Transfer laser cut
part bushing (bronz)
1
HM-07-09
Special pedal washer
2
HM-06-86
Ø6 x 16 cross
recessed raised
cheese head screws
2
HM-11-34
Ø13 rue segman
1
HM-06-001 M6 x 25 mushroom
head square neck
bolt
1
Caster kit, dual
wheel no steer lock,
antistatic (150 mm)
YM-KIT-100041 HM-01-86
2946USP150R36-
32S30 D RAL 9002
4XM6 TENTE 150
mm double no steer
1
