Stryker SV2 Service Manual

94 SK-7500 REV 00 www.stryker.com
Siderail foot end assembly
Item Number Name
Quantity
A YM-02-142-MN1
SV2 left siderail for foot
1
B HM-11-19
Ø10 hook ring
2
C
HM-02-283
Ø10x2 mm plastic washer
6
D YM-HM-02-029
Side board lock plastic-
short
1
E HM-12-005 10x123,5 mm siderail pin
1
F YM-HM-02-028
Side board lock plastic-
long
2
G
HM-12-145
Ø10x305 mm siderail pin
1
H HM-11-31
Ø10 rue clip
2
Siderail laminate
Number (left) Number (right)
Dark blue HM-20-855 HM-20-854
Dark wood HM-20-762 HM-20-761
Light wood HM-20-752 HM-20-751
Wood HM-20-757 HM-20-756
