Stryker SV2 Service Manual

14 SK-7500 REV 00 www.stryker.com
Quick reference replacement parts
These parts are currently available for purchase. Call Stryker Customer Service: + 90 (352) 321 43 00 (pbx) for
availability and pricing.
Kit name Number Kit contents
Number Name
Quantity
Actuator kit, Fowler
(backrest)
YM-KIT-100049 HM-11-31
Ø 10 rue clip
2
HM-12-FTR010
Ø14xØ10x65 mm
2
HM-17-303
4000 N LA40 QR 215
mm actuator
1
YM-HM-02-027
Actuator pin fixing
bush
1
Actuator kit, gatch
(legrest)
YM-KIT-100051 HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
2
HM-11-31
Ø10 rue clip
3
HM-12-FTR010
Ø14xØ10x65 mm
1
HM-12-FTR009
Actuator calf pin
10x96, 5 mm
1
HM-17-305 6000 N LA40 100
mm stroke actuator
1
YM-HM-02-070
5 mm PLS washer
(inside diameter 10
mm washer)
2
YM-HM-02-287
10*14 mm PLS
washer mould NO 36
2
YM-HM-02-027
Actuator pin fixing
bush
1
Actuator kit, lift
YM-KIT-100050 HM-11-31
Ø10 rue clip
2
HM-12-FTR010
Ø14xØ10x65 mm
actuator connection
pin
1
HM-12-FTR011 10x41 mm actuator
connection pin
1
HM-17-304 J13205-8000 N LA40
150 mm stroke
actuator
1
YM-HM-02-027
Actuator pin fixing
bush
1
Battery replacement
kit
YM-KIT-100001 HM-05-043 M5*20 imbus bolt
4
HM-07-22 M6 iron washer
(small)
4
HM-08-04
M5 fibered nut
4
HM-16-03
Ø25 clips (UB250C-
N 245x4,6 cable
connector)
2
