Stryker SV2 Service Manual

www.stryker.com SK-7500 REV 00 93
Siderail head end assembly
Item Number Name
Quantity
A YM-02-144-MN1
SV2 right foot siderail
assembly
1
B HM-12-145
Ø10x305 mm siderail pin
1
C
HM-02-283
Ø10x2 mm plastic washer
6
D HM-11-19
Ø10 hook ring
2
E HM-12-005 10x123.5 mm siderail pin
1
F YM-HM-02-028
Side board lock plastic-
long
2
G
YM-HM-02-029
Side board lock plastic-
short
1
H HM-11-31
Ø10 rue clip
2
Siderail laminate
Number (left) Number (right)
Dark blue HM-20-853 HM-20-852
Dark wood HM-20-760 HM-20-759
Light wood HM-20-750 HM-20-749
Wood HM-20-755 HM-20-754
