Stryker SV2 Service Manual

www.stryker.com SK-7500 REV 00 85
Control box and battery
Item Number Name
Quantity
A
HM-17-16 BA1812-1300-000 Linak
CB6 battery
1
B HM-05-043 M5*20 imbus bolt 4
C
HM-07-22 M6 iron washer (small)
6
D
HM-08-04
M5 fibered nut 4
E
YM-03-03-01-0425-HZR 5 x 20 mm battery
mounting bracket
2
F
HM-06-049
3.9 x 16 mm pan head self
drilling screw
4
G
HM-17-314
Control box 1
H
HM-05-010 M6*50 steel bolt 1
I
HM-08-05
M6 fibered nut 1
J
HM-17-174
Control box mounting
bracket
1
K
HM-06-02
3.9 x 13 mm pan head self
drilling screw
2
L
HM-07-01 M6 metal standard washer
(large) 1/4 washer
2
