Stryker SV2 Service Manual

www.stryker.com SK-7500 REV 00 19
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
HM-09-30 M6 toothed washer
(DIN 6797 A)
2
HM-11-34
Ø13 rue clip
2
YM-HM-02-71
12 thick PLS washer
DMR071
2
YM-HM-02-299
50*50 caster profile
cap PLS (lower
chasis PLS) 51
mould
1
HM-11-10
11 mm Snap ring
(lipper) KMS starlock
push on BV/6706
fastener
1
Fifth wheel assembly
kit
YM-KIT-100084 YM-5TKR-001 5.wheel assembly
group
1
YM-04-142-BY
5.wheel-base frame
connection sheet
2
HM-07-22 M6 steel washer
(small)
4
HM-05-041 M6*30 hexagon
socket button head
screw
4
HM-12-004
Ø8 perforated pin
1
HM-11-35
Ø8 rue clip
1
YM-HM-02-026 8,5 x 16 x 2,2 mm
plastic washer
1
Fifth wheel
replacement kit
YM-KIT-100085 HM-01-32
Tente PJO100x32-
Ø12 - wheel
1
YM-HM-02-030 5th wheel - wheel
washer
2
HM-07-03 M8 steel washer 2
HM-08-06
M8 self-lock hex nut
1
HM-05-048 M8*60 hexagon
socket button head
screw
1
Control box
replacement kit
YM-KIT-100040 HM-05-010 M6*50 steel bolt
1
HM-07-01 M6 metal standard
washer (large) 1/4
washer
2
HM-08-05
M6 fibered nut
1
HM-17-373
SV2 control box
CB6777-00
1
