Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
YM-HM-02-418 Future side rail shock
absorber PLS
2
HM-07-03 M8 iron washer 2
HM-08-06
M8 fibered nut
1
HM-20-557
Ø15 clips
1
Footrest siderail gas
cylinder kit
YM-KIT-100038 HM-11-18
Q8 capped snap ring
(DT/6671/43A)
2
HM-12-146 12-146 8 x 31 mm
side rail pin
1
HM-18-27 Future side rail shock
absorber 640015004
1
HM-11-05
6 mm C shape snap
ring DIN 6799
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
2
HM-12-FTR005
Shock absorber
connection pin
1
Siderail kit, foot end
left
YM-KIT-100052 YM-02-142-MN1
SV2 Left foot siderail
assembly
1
HM-12-FTR005 12-FTR005 shock
absorber connection
pin
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
6
HM-11-05
6 mm C shape snap
ring DIN 6799
1
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
2
HM-11-31
Ø10 rue clip
2
HM-12-005 10x123,5 mm siderail
pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-028
Side board lock
plastic-long
2
YM-HM-02-029
Side board lock
plastic-short
1
HM-22-1780 3M primer 94
handkerchief
1
