Stryker SV2 Service Manual

32 SK-7500 REV 00 www.stryker.com
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
HM-12-005 10x123,5 mm siderail
pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-028
Side board lock
plastic-long
2
YM-HM-02-029
Side board lock
plastic-short
1
HM-22-1780 3M primer 94
handkerchief
1
HM-20-394
Warning, crushing of
hands label
1
Siderail kit, foot end
right, dark blue
YM-KIT-100053-B YM-02-144-MN1
SV2 Right foot
siderail assembly
1
HM-12-FTR005 12-FTR005 shock
absorber connection
pin
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
6
HM-11-05
6 mm C shape snap
ring DIN 6799
1
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
2
HM-11-31
Ø10 rue clip
2
HM-12-005 10x123,5 mm siderail
pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-028
Side board lock
plastic-long
2
YM-HM-02-029
Side board lock
plastic-short
1
HM-22-1780 3M primer 94
handkerchief
1
HM-20-394
Warning, crushing of
hands label
1
HM-20-874
SV2 dark blue
(Stryker) lower left
siderail color sticker
1
Siderail kit, foot end
right, dark wood
YM-KIT-100053-D YM-02-144-MN1
SV2 Right foot
siderail assembly
1
