Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Siderail kit, head end
left W/O unit, dark
blue
YM-KIT-100056-B YM-02-141-MN4
SV2 Back left siderail
assembly w/o unit
1
HM-22-1780 3M primer 94
handkerchief
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
4
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
2
HM-12-005 10x123,5 mm siderail
pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-418 Future siderail shock
absorber PLS
2
HM-05-018
M8*90 half thread
steel bolt
1
HM-07-03 M8 iron washer 2
HM-08-06
M8 fibered nut
1
HM-11-31
Ø10 rue clip
2
YM-HM-02-028
Side board lock
plastic-long
2
YM-HM-02-029
Side board lock
plastic-short
1
HM-20-394
Warning, crushing of
hands label
1
HM-20-873
SV2 dark blue
(Stryker) upper left
siderail color sticker
1
Siderail kit, head end
left W/O unit, dark
wood
YM-KIT-100056-D YM-02-141-MN4
SV2 Back left siderail
assembly w/o unit
1
HM-22-1780 3M primer 94
handkerchief
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
4
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
2
HM-12-005 10x123,5 mm siderail
pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
