74 SK-7500 REV 00 www.stryker.com
Brake system
Item Number Name
Quantity
E HM-01-54
2046UAP150R36-32S30
150 mm no steer lock not
antistatic single caster
3
F HM-09-04 DIN 6798 A/J - M6 serrated
lock washer
1
G
HM-05-106 M6*16 imbus bolt 8
H YM-HM-02-299
Hexagonal shaft bearing
part
4
I YM-HM-02-71
12 thick PLS washer
DMR071
4
J HM-09-18
Ø10 rivet nut
2
K HM-16-113 260 mm grounding cable
1
L HM-06-02 3,9 x 13 cross recessed
pan head tapping screw
1
M HM-09-23 M6 rivet nut
4
N YM-5TKR-001 5.wheel assembly group
1
O
HM-05-041 M6*30 hexagon socket
button head screw
4
P HM-07-22 M6 iron washer (small) 8
Q
HM-11-34
Ø13 rue segman
4
R HM-20-424
Pedal label - left
2
S
HM-20-423 Pedal label - right 2
T HM-12-004
Ø8 perforated pin
1
U YM-HM-02-026 8,5 x 16 x 2,2 mm plastic
washer
2
V HM-11-35
Ø8 rue clip
1
W YM-HM-02-023 Pedal plastic body
4
X
YM-SV2PDL-001-BY
Pedal sheet weld assembly
4
Y HM-07-09
Special pedal washer
8
Z HM-06-86
Ø6 x 16 cross recessed
raised cheese head screws
8
AA HM-06-001 M6 x 25 mushroom head
square neck bolt
4
AB HM-12-905
Transfer laser bush
(bronze)
4
AC
HM-08-05
M6 fibered nut
4
AD YM-04-142-BY
5. wheel - base frame
connection sheet
2
AE YM-HM-02-025
Transfer bar Ø8 plastic
hole cap
1
