Stryker SV2 - Gatch Assembly Component List (Continued)

www.stryker.com SK-7500 REV 00 87
Litter fowler (backrest) assembly
Item Number Name
Quantity
M HM-08-35 M8 rivet nut 6
N HM-11-03 10 mm snap ring DIN 471 2
O
HM-02-283 2 mm plastic washer (10
mm plastic washer) mould
NO 34
14
P HM-12-103
Ø10 x 44.5 mm pin
2
Q
HM-06-72
Ø5.5 x 19mm torque screw
6
R HM-05-005
Ø10 x 35 mm hex head bolt
4
S
YM-HM-02-88
Ø10 mm plastic bushing
8
T HM-07-04 M10 iron washer 8
U HM-08-07
M10 fiber hex nut
8
V HM-06-89 M10 x 55 mm carriage bolt
4
W
YM-FUTURELBUST-001-
BY
Litter frame weldment
1
