Stryker SV2 - Siderail Head End Assembly Parts; Head End Siderail Component List

90 SK-7500 REV 00 www.stryker.com
Litter gatch (legrest) assembly
Item Number Name
Quantity
O
HM-06-88 M8 x 47 mm carriage bolt 2
P HM-07-03 M8 iron washer 2
Q
HM-08-06
M8 fibered nut
2
R HM-06-66 M6 x 15 mm button head
screw
1
S
YM-HM-02-55
Ø9 x 12.4 mm plastic
screw
2
T
YM-FUTURELBUST-001-
BY
Litter frame weldment
1
