Micro Series
1-72 Micro Series
Document generated: 29.06.17
SW V1.1
[5] Function Defines the function that is triggered from the GPI
[6] Parameters Depending on the GPI Function, a parameter of the function can be chosen
here. (E.g. a channel number).
The two following tables show all Input Functions :
Momentary only or momentary and latching functions :
Function Argument 1 Argument 2 Argument 2 Description
CHANNEL ON
Channel 1..12
Send 1..4
-- - Activate/Deactivate the specified On/Off
CHANNEL PFL
Channel 1..12
Send 1..4
PRG, REC
- - Activate/Deactivate the specified PFL On/Off
COUGH Channel 1..12 - -
Activate/Deactivate TB Mic Cut of the specified Chan-
nel
TALKBACK
Source :
TBfromCh1..12
TBfromExtern
Destination :
TBtoCR
TBtoDJ
TBtoGuest
TBtoSend1..4
TBtoExtern
-
Activate/Deactivate TB from specified source todes-
tination
LSP CUT - - - Activate/Deactivate the loudspeaker Cut
LSP DIM - - - Activate/Deactivate the loudspeaker Dim
Event driven functions:
Function Argument 1 Argument 2 Argument 2 Description
SET CR MON SRC
PRG, REC
Send1..4
EXTERN
Set the specified source for the CR monitoring
SET GUEST MON SRC
PRG, REC
Send1..4
EXTERN
FOLLOW CR
Set the specified source for the Guest monitoring
LOAD SNAPSHOT Snapshot name Recall the specified snapshot
TRACK PLAYER
NEXT
STOP
Start the next track in the Playlist
Stop the Playlist
