1-6 Sun Fire V210 and V240 Servers Administration Guide • December 2005
FIGURE 1-3 Location of Status Indicators (Sun Fire V210 Server)
1.2.1 Server Status Indicators
The server has three LED status indicators. They are located on the front bezel, and
repeated on the back panel. A summary of the indicators is given in
TABLE 1-2.
TABLE 1-2 Server Status Indicators
Indicator LED color LED State Meaning
Activity Green On The server is powered up and running the
Solaris OS.
Off Either power is not present, or Solaris OS is
not running.
Locator LED
Service required LED
Activity LED
