Chapter 2 Removing and Replacing Components 2-13
Caution – Follow the instructions in this section carefully. The DVD-ROM drive
contains a laser device. Do not attempt to open the DVD-ROM drive’s enclosure or
remove a DVD-ROM drive using any procedures other than those contained in this
section. If you do, you risk being exposed to radiation.
2.6.1 Removing the DVD Drive
1. Power down the server.
See Section 2.3, “Controlling Server Power” on page 2-4.
2. Open the bezel.
See Section 2.2.2, “Opening the Front Bezel” on page 2-2.
3. Unclip the catches that fasten the DVD drive to the chassis (FIGURE 2-5).
4. Pull the DVD drive towards you until it is free of its connectors and out of the
chassis.
2.6.2 Replacing the DVD Drive
1. Insert the new DVD-ROM drive.
2. Press it home firmly until the clips engage with the server’s chassis.
3. Close the bezel.
Class 1 Laser Product
Luokan 1 Laserlaite
Klasse 1 Laser Apparat
Laser Klasse 1
