Chapter 1 Introduction 1-15
1.2.10 Keyswitch
The Sun Fire V240 server has a keyswitch that provides control over the following
aspects of the server’s operation:
■ Power state
■ Security level
■ Diagnostics level
Located behind the front bezel is a rotary switch with four positions, operated by a
key supplied with the server. The key is shipped in a clip on the back of the bezel.
FIGURE 1-6 Location of the Keyswitch (Sun Fire V240 Server)
The keyswitch has four positions, each keyswitch position enables the user to select
a different mode of behavior. For a description of the behavior forced by each
keyswitch position, see
TABLE 1-7.
Keyswitch
