Chapter 1 Introduction 1-11
1.2.7 Hard Drives
The Sun Fire V210 server has slots for up to two hard drives. The Sun Fire V240
server has slots for up to four. The slots accept any Sun LVD SCSI hard drive
conforming to the 1-inch SCA-2 form factor.
Each hard drive has two LED indicators associated with it. See TABLE 1-5 for a
summary of what the indicators mean.
FIGURE 1-5 Location of Hard Drive Service Indicators
For information on removing and replacing a hard drive, see Section 2.5, “Removing
and Replacing Hard Drives” on page 2-7.
TABLE 1-5 Hard Drive Service Indicators
Indicator LED color LED State Component Status
Activity Green Flashing Active SCSI transactions
Off No activity
Ready to Remove Blue On Ready to remove
Off Not ready to remove
Activity
Ready to remove
