Appendix B Product Specifications B-3
B.2 Electrical Specifications
TABLE B-2 lists electrical specifications for the Sun Ultra 45 or Ultra 25 workstation.
TABLE B-3 lists the power supply specifications.
B.3 Acoustic Specifications
TABLE B-4 lists acoustic specifications for the Sun Ultra 45 or Ultra 25 workstation.
TABLE B-2 Electrical Specifications
Maximum AC Input Voltage Current Frequency
Range 1 100 VAC 12 amps 50 – 60 Hz
Range 2 110 – 127 VAC 10 amps 50 – 60 Hz
Range 3 200 – 240 VAC 6 amps 50 – 60 Hz
TABLE B-3 Power Supply Specifications
Specification Value
Input Voltage 100 – 127 VAC, 200 – 240 VAC
Frequency 50 – 60 Hz
Current 6.4 amps @ 100 VAC, 3.2 Amps at 200 VAC
Wattage 630 W input (Power supply rated at 1,000 W maximum)
TABLE B-4 Declared Noise Emissions: ISO 9296
Specification Operating Idling
LWAd (1B=10db) 5.0 B 4.5 B
LpAm (by standard
position)
42 dBA 38 dBA
