84
Step 3 After cleaning, install the filter in reverse steps.
- - End
11.3.3 Cleaning Air Inlet of Power Distribution Cabinet
Step 1 Remove the screws from the upper air inlet of the power distribution cabinet using a
screwdriver.
Step 2 Move the filter cotton at the air inlet downward, take out the filter cotton and clean it.
Step 3 Reinstall the filter cotton in reverse steps.
* The figure is for reference only. And the actual product received shall prevail.
- - End
11.3.4 Cleaning Air Outlet of Power Distribution Cabinet
Step 1 Pull downward the spring plunger on the air outlet at the bottom of the power distribution
cabinet.
Step 2 Pull out the filter at the air outlet and clean it.
Step 3 Reinstall the filter in reverse steps.
* The figure is for reference only. And the actual product received shall prevail.
11 Routine Maintenance System Manual
