Example:
This example shows the battery being charged up to 100% by both the Grid and Solar PV from 8 a.m. to 11
a.m. and then being able to supply up to 4kW of battery-power to the ‘essential’ loads from the ‘Load’ Port
until the battery SOC drops to 50%.
IMPORTANT - When charging the batteries from the Grid or Generator, please ensure you have set the
correct battery-charging settings on the battery charge as shown in Section 4.10 ‘Battery Setup’ Home Page.
If the ‘Use Timer’ function is activated then the inverter will use the battery power according to your settings
when the Grid is present. If this function is not set, the batteries WILL ONLY be used for backup when there
is no utility grid power.
Example:
The power produced is supplying the ‘Non-Essential Load’ while the inverter is set at a maximum power
of 8kW (Max Sell Power). The inverter is connected to the grid, but no export is performed. The unit allows
small amounts of power to ow from the Grid (100W Zero Export Power) to prevent any back-ow. In this
example, the solar PV is prioritised to supply the Load rst and then subsequently, charge the battery.
To Next Page
