SWE90UF-2PB Operation & Maintenance Manual
Right turning: push left handle forward.
In order to protect travel mechanism, turning should be
avoided as possible as you can while backing.
Travel direction label：
Travel speed
During the machine traveling, press high/low speed switch on control panel to shift the travel motor speed
between high and low, then the machine can travel at high or low speed.
Travel brake
Release travel pedal or travel handle, it will return to neutral position automatically, the machine stops
traveling.
Key points of travelling
(1) Arm and bucket cylinder must be extended completely
to place the working device on minimum radius position, the
bucket will be about 0.5m above the ground.
(2) Lift dozer blade to the highest position.
(3) Choose flat road to travel as much as possible. It should
travel straight when traveling or turning, and also make a wide
turn, avoiding a sharp one. When turning in one point at
confined area, the operation should be gentle.
(4) When travelling on badlands or uneven cobblestone
road, rotation speed of diesel engine should be reduced,
travelling at about 1.5km/h to reduce the vibration.
(5) Avoid travel rearward to prevent crawler parts
damaging prematurely.
(6)
(7) If the excavator can’t travel for getting into mud,
extend arm and place bucket on ground (as figure) to lift one
