Networking solar inverters via
RS485 interface
If you want to monitor a solar system
with Sunways Solar Inverters both the NT
series and the AT series together, then
you can use the RS485 interface integrat
-
ed in the solar inverters for this purpose.
This function is supported from AT Com
-
munication Software Version 2.0002. If
necessary, carry out a software update
(see the chapter Software Update). The
system networked with the RS485 inter
-
face can be monitored with the Sunways
Communicator.
Use a twisted two-wire cable to network
the solar inverters with each other.
Mount the terminating resistor on the
last solar inverter.
NT 10000:
RS485MATCH jumper,
NT 2600...NT 6000:
JP400 jumper
NT 10000 NT 2600...
NT 6000
AT Serie AT Serie
Sunways
Communicator
