7.1 Technical data
Model AT 5000 AT 4500 AT 3600 AT 2700
DC Input
Rated DC power 5200 W 4700 W 3750 W 2800 W
Maximum DC current 22,0 A 22,0 A 15,5 A 15,5 A
Nominal DC voltage 350 V
MPP voltage range 236...600 V 214...600 V 242...600 V 181...600 V
Maximum voltage DC 680 V
Number of inputs per MPP
tracker
2 x Tyco Solarlok
Number of MPP trackers
1
AC output
Rated AC output power 5000 W 4500 W 3600 W 2700 W
Maximum AC power 5000 W 4500 W 3600 W 2700 W
Nominal AC current 21,7 A 19,6 A 15,7 A 11,7 A
Maximum AC current 23,0 A 21,0 A 17,0 A 12,5 A
Nominal frequency 50 Hz
Frequency tolerance range 47,5...50,2 Hz (according to DIN VDE 0126-1-1)
Grid voltage 230 V
AC voltage range -20%...+15% (according to DIN VDE 0126-1-1)
Distortion factor at Pn < 4%
Reactive power factor (cos phi) ca. 1
Grid voltage monitoring according to DIN VDE 0126-1-1
Earth fault protection RCD (according to DIN VDE 0126-1-1)
