Keyboard
The keyboard can be used to navigate in
the menu, edit text fields, select entries
from lists and enter numbers consecu
-
tively and digit by digit. User entries can
only be made if the value to be changed
is selected. The cursor changes visibly in
the editing mode and indicates the digit
to be changed.
key Scroll up.
key Scroll down.
key Select menu item.
key Back one menu level.
key Select menu item and
confirm your entries.
key Cancel.
Operating LED
The combined red/green LED indicates
the unit status of the solar inverter:
· LED off
Solar inverter is not active (night
mode)
· LED green, continuously lit
Solar inverter is active and feeds into
power grid (MPP mode)
· LED green, flashing
Solar inverter is active and feeds into
power grid, however with current,
output or temperature limitation.
· LED red, continuously lit
an error has occurred (malfunction)
· LED red, flashing
a warning has been issued
