25
Installation
Proceed as follows to install the solar
inverter:
1. Hold the wall bracket at the point at
which you want to attach the solar
inverter and mark the mounting holes.
2. Drill the holes with a 10 mm dia. drill
bit.
3. Install the wall bracket with corre
-
sponding screws and dowels depend
-
ing on the surface condition.
4. Unscrew the locking screw of the solar
inverter at the lower left with an Allen
key
5. Hook the solar inverter into the cut-
outs of the installation frame at the
top on both sides.
6. Secure the solar inverter by tightening
the locking screw.
