1 LCD display (lighted)
2 Operating LED
3 Keyboard
LCD display
A graphics-capable, monochrome dot
matrix display is integrated in the oper-
ating field. In standard operation the
momentary output, daily yield and status
are displayed. The bar graph shows the
energy feed-in of the current day.
Press any key to activate the display light
-
ing. If no key is pressed for approx.
1 minute, the display lighting goes out.
Important!
The LCD display is not a calibrated
measuring device. It is characterised by a
slight, system-dependent difference of a
few percent.
Exact accounting of the data with the
power supply company requires a cali
-
brated meter.
