In case of Door (When using the internal relay)
※ Opening Mode
- Temporary Open: When the door is open, it is automatically closed after a specific time.
- Toggle: The door is opened after the first authorization success and it remains unlocked
until the second authorization success.
※ It is used only when the stand-alone BioLite Net is installed without
interoperating with the dedicated PC software.
Item
Door
In/Out
Use ◀/▶ buttons
to select Door and
press OK.
Use ◀/▶ buttons
to select Internal
and press OK.
Use ◀/▶ buttons to select
Exit Button and press OK.
* Not Use/ Input 0/ Input 1
Relay
Internal
Door
Exit Button
Input 0
Internal
Use ◀/▶ buttons to
select the type for Exit
Button and press OK.
*N.O/N.C
Type
N.O
Exit Button
Door Sensor
Input 1
Internal
Use ◀/▶ buttons to
select a door sensor type
and press OK.
*N.O/N.C
Use ◀/▶ buttons to
select Door Sensor and
press OK.
*
Not Use/Input
Opening Mode
Temporary Open
Door
Held Open Alarm
Not Use
Door
Open Time(sec)
3
Door
Type
N.O
Door Sensor
Use ◀/▶ buttons to
select a opening mode
and press OK.
*Temporary Open/ Toggle
Enter the time and
press OK.
Use ◀/▶ buttons to select
the type for Held Open Alarm
and press OK.
* Not Use /Sound/Backlight/
Sound& Light/SIO Relay0/
SIO Relay1
Enter the held open time by
using the Numeric buttons
and press OK.
*Held Open Time: Alarm
ringing time when the open
door is not closed.
Forced Open Alarm
Not Use
Door
Completed
Use ◀/▶ buttons to select the
type for Forced Open Alarm and
press OK.
*Not Use/Sound/ Backlight/Sound
and Light/SIO Relay0/ SIO Relay1
The completion
message window
appears.
Held Open Time(sec)
30
Door
When you exit from the menu before completing the relay setup, the
configuration is not stored so please finish configuration until the
message “Complete” appears.
