SUSS MJB4 - Programs

OPERATION OF THE MJB4
MJB4 - Operation Rev07 05-10 37
3
3.8.2. Programs
Saving a New Program
All active parameters are stored under a selected program name.
Selecting an Existing Program
All parameters stored under the respective program number are activated.
Menu in the Display Button Strokes in the Display
MAIN MENU PARAMETERS
PARAMETERS Edit parameters
PARAMETERS Load
MAIN MENU Recipes
RECIPE EDITOR Select available program space
RECIPE EDITOR New
ALPHANUM. KEYBOARD Enter program name
RECIPE EDITOR Load
All parameters stored under the program name
are displayed and saved
MAIN MENU
Menu in the Display Button Strokes in the Display
MAIN MENU RECIPES
RECIPE EDITOR SELECT
Select existing program space
RECIPE EDITOR
LOAD
The display switches back to the main menu
The machine is ready for use
MAIN MENU
